Sensor Gate BS-DS7200G

Price 7195,50 € (23% VAT included)
5850,00 € net price
DESCRIPTION
The STARK Speed Gate DS7200G is a luxury ultra-fast swing barrier with a slim golden design, suitable for both indoor and outdoor environments; featuring IP65 waterproof protection, adjustable passage width up to 900 mm and optional arm height up to 1800 mm, it delivers high security and user comfort, while illuminated plexiglass arms enhance the visual appeal and prestige of the installation site.
PRODUCT MAIN FEATURES:
-
IP65 waterproof protection – suitable for outdoor use
-
Ultra-fast opening and closing speed up to 0.2 sec (adjustable)
-
Slim, luxury golden housing design
-
Passage width options:
-
600 mm standard
-
up to 900 mm for wide access and wheelchair passage
-
-
Arm height option up to 1800 mm for high-security applications
-
Plexiglass swing arms with decorative LED lighting
-
Selectable single-direction or bi-directional operation
-
Automatic reset if passage is delayed
-
Automatic arm opening during power failure (fire safety compliant)
-
Advanced security features:
-
anti-intrusion
-
anti-reverse entry
-
anti-tailgating
-
-
Automatic arm reset after strong impact without damage
-
Smooth, low-noise operation
-
Easy installation and maintenance
-
3-year manufacturer warranty

DIMENSIONS

TECHNICAL DATA
| Framework Material | Steel with golden stoving varnish (standard), AISI 304 stainless steel (optional) |
| Arm Material | Transparent plexiglass (middle panel), tempered glass (side panels) |
| Dimensions (L×W×H) | 1200 × 120 × 1000 mm |
| Weight | ~80 kg/unit (single core), ~100 kg/unit (double core) |
| Passage Width | 600–900 mm (single lane) |
| Arm Height | 900 mm (standard), ≤1800 mm (optional) |
| Passing Direction | Single-directional or bi-directional |
| MCBF | 15,000,000 cycles |
| Power Supply | AC 220V / 110V, 50 Hz |
| Operating Voltage | 24 V DC |
| Power Consumption | 60–90 W |
| Operating Temperature | -15°C to +75°C |
| Operating Humidity | 0–90% (non-condensing) |
| Working Environment | Indoor / outdoor |
| Flow Rate | Up to 55 people/min |
| LED Indicator | Yes |
| Infrared Sensors | 6 pairs (standard) |
| Emergency Mode | Automatic arm opening when power off |
| Communication | Dry contact, relay signal, RS485 |
